Hillquist

HILLQUIST Slab Saw & Trim Saw

Product code: MX-21303

CABINET - one piece molded fiberglass

Prices are quoted, not listed. Add this product to your quote request and we reply with pricing and availability, usually within one business day. No payment, no account, no minimum order.

1

Ask about this product on LINE

Prefer to talk? Call +66 99 241 5692, email us or chat on LINE.

Product description

The Hillquist Thin Section Machine

  • CABINET - one piece molded fiberglass
  • MOTOR - heavy duty 1/2 HP-1725 RPM 50 or 60 HZ
  • CAPACITY - 1" rounds to 2" x 3" slides - no special adapters needed
  • BLADE - 8" x .050" HCR-100 Hillquist continuous rim blade - high concentration diamond
  • LAP - 8" diamond cup wheel - 1/8" depth of diamond - metal bonded - 240 or 320 mesh
  • ARMS - anodized aluminum alloy - ceramic mounting surfaces - aluminum and nylon guides - adjustable
  • COOLANT SYSTEM - two compartment settling tank - submersible pump - compatible with water and oil base coolants - individual control valves
  • THICKNESS GAUGE - precision dial indicator - .01 mm gradations
  • LAMP - adjustable operator's lamp
  • STOPS - prevent damage to arms and dial indicator
  • DIMENSIONS - 38" x 21"x 11'
  • WEIGHT - 100 lbs.

The Hillquist Thin Section Grinder

  • CABINET - one piece molded fiberglass
  • LAP - 8" x 3/8"full coat metal bonded diamond
  • MOTOR -1/4 HP-permanent magnet D.C.
  • VARIABLE SPEED - full wave SCR control - 1 to 350 RPM with constant torque
  • DRIVE - maintenance free gear belt
  • ARBOR - 3/4" ground and polished steel - factory lubricated sealed bearings - 8" diameter anodized aluminum base plate
  • COOLANT SYSTEM - two compartment settling tank - submersible pump - compatible with water and oil base coolants - control valves
  • DIMENSIONS - 26" x 22"x 10'
  • WEIGHT - 43 lbs.

The Hillquist SF-8 Trim Saw

​

  • CABINET - one piece molded fiberglass
  • CUTTING TABLE - 13" x 17" cutting area - raised stainless steel rails
  • ARBOR - precision ground 5/8" stainless steel - factory lubricated and sealed bearings
  • BLADE - 8" x .060" HCR-50 Hillquist continuous rim blade - high concentration diamond
  • CUTTING GUIDE - three position gauge for cutting of standard petrographic rock chip
  • GUARDS - Formed aluminum blade and belt guards
  • COOLANT SYSTEM - two compartment settling tank - submersible pump - compatible with water and oil base coolants
  • MOTOR - 1/3 HP-1725 RPM
  • DIMENSIONS - 26" x 20"x 11'
  • WEIGHT - 35 lbs.
